Side Entry Wrapping Machine CCP-EC50
Information
Characteristic:
WJ-WA type automatic carton box packing machine is a new generation machine which combined with foreign advanced technology and our national condition. This is a our self-developed high efficiency and environmental protection machine which has independent intellectual property rights and is widely use in packing industry.
Corrugated box is a paper container which made of corrugated board. Advantages are as following:
Similar as arched structure, it can control erosion and reduce shock, have good mechanical properties.
Have good protect function. Such as dampproof, heat radiation, easy handling, etc.
Low transportation expenses, can easy to realize mechanization and automation of transporting and packing. Easy change specification and size, can quickly adapt to the packaging of all kinds of goods.
Easy box and bundle, easy automatic operation.
Can adapt to decoration printing of all kinds of carton box, can well solve the problem of product protection and promotion.
Greatly expand its scope of use through the combination of various coverings and dampproof materials.
The packing box is beautiful, product grades and image appearance get further improved.
In a word, use automatic wrap packing machine can reduce work strength, labor source and production process. It overall performance index and economic benefits are obvious and are commonly accepted by society. This will be an upgrade in traditional packing way and is the inevitable development trend.
Application:
Applicable to mineral water, beverage, medical, chemical and other product line corollary equipment, finish the final enchasing process in product line.
Product Encyclopedia
Side Entry Wrapping Machine CCP-EC50: Comprehensive Guide to Automated Side Entry Packaging Solutions
The Side Entry Wrapping Machine CCP-EC50 is an advanced packaging system designed to automate the wrapping of products from the side entry point. This innovative machine improves packaging efficiency, reduces labor requirements, and ensures consistent product protection. Its application spans multiple industries, including beverages, food, pharmaceuticals, cosmetics, and industrial products.
As modern production lines demand higher speed, precision, and reliability, the Side Entry Wrapping Machine CCP-EC50 has become a vital tool for manufacturers seeking to optimize packaging processes while maintaining high-quality standards.
What is a Side Entry Wrapping Machine CCP-EC50?
A Side Entry Wrapping Machine CCP-EC50 is an automated packaging system that wraps products using plastic film, shrink film, or other flexible materials, entering from the side of the machine. The side-entry design allows for seamless integration into existing conveyor lines, especially in high-speed or continuous production environments.
Key Functions
Automatic product feeding from the side entry
Precise film application
Heat shrinking or sealing
Smooth product discharge
Integration with other packaging line equipment
Core Features of Side Entry Wrapping Machine CCP-EC50
1. High-Speed Packaging Performance
The CCP-EC50 supports continuous high-speed wrapping operations, making it ideal for industrial-scale production.
2. Side Entry Flexibility
Side entry design simplifies the integration of wrapping into existing production lines without extensive modifications.
3. Reliable Film Application
Advanced mechanisms ensure uniform film wrapping and consistent product protection.
4. Adjustable Product Sizes
Supports various product dimensions, offering flexibility for different packaging requirements.
5. Intelligent Control System
Equipped with PLC or touch screen controls, allowing operators to monitor and adjust parameters efficiently.
Advantages of Side Entry Wrapping Machine CCP-EC50
| Advantage | Description |
|---|---|
| Increased Efficiency | Automates wrapping to increase throughput |
| Reduced Labor | Minimizes manual intervention |
| Consistent Packaging | Ensures uniform film application and tight wrapping |
| Flexible Product Handling | Adapts to multiple product sizes and types |
| Durable Design | Built for long-term industrial use |
| Easy Integration | Compatible with conveyor and production lines |
Working Principle of Side Entry Wrapping Machine CCP-EC50
The Side Entry Wrapping Machine CCP-EC50 operates through several coordinated stages:
Product Feeding: Items enter the machine from the side, typically via a conveyor system.
Product Alignment: Guides and sensors ensure products are correctly positioned for wrapping.
Film Application: Film is fed from the roll and wrapped around the product.
Sealing and Shrinking: Heat sealing or shrinking is applied to secure the packaging.
Cooling and Discharge: Wrapped products are cooled if necessary and discharged for shipping or storage.
Technical Specifications of Side Entry Wrapping Machine CCP-EC50
| Parameter | Specification |
|---|---|
| Model | Side Entry Wrapping Machine CCP-EC50 |
| Wrapping Speed | 15–25 packs per minute |
| Product Size Range | L 50–300 mm, W 50–200 mm, H 50–400 mm |
| Film Type | PE, PVC, or shrink film |
| Power Supply | 380V, 50Hz |
| Power Consumption | 5–15 kW |
| Air Pressure | 0.5–0.7 MPa |
| Machine Dimensions | 2000 × 1200 × 1800 mm |
| Weight | Approx. 600 kg |
Applications of Side Entry Wrapping Machine CCP-EC50
Beverage Industry
Used for bottles, cans, and multipacks of beverages.
Food Industry
Packaging of sauces, condiments, and snack items.
Pharmaceutical Industry
Wrapping liquid medicines, syrups, and small packages.
Cosmetic Industry
Used for bottles of shampoo, lotions, and other personal care products.
Industrial Products
Packaging hardware, small electronic components, and household goods.
Types of Wrapping Methods
| Method | Description | Typical Application |
|---|---|---|
| Shrink Film | Heat-shrinkable film applied around the product | Bottles, cans |
| Stretch Film | Stretchable plastic film to secure multiple items | Multipacks, cases |
| Heat Sealing | Plastic film sealed by heating elements | Soft pouches or bottles |
| Bundling | Side entry aligns products for group wrapping | Multipacks for shipping |
Comparison: Side Entry vs Top Entry Wrapping Machines
| Feature | Side Entry | Top Entry |
|---|---|---|
| Integration | Easier with conveyor lines | May require redesign of line |
| Packaging Speed | High | Moderate |
| Product Accessibility | Easy side access | Limited side access |
| Film Utilization | Efficient | Slightly higher waste |
| Space Requirement | Compact | Larger footprint |
Key Components of Side Entry Wrapping Machine CCP-EC50
Side Entry Conveyor: Guides products into the machine.
Film Feeding System: Rolls and applies film precisely.
Sealing Mechanism: Ensures tight and secure packaging.
Heat Shrink Tunnel: Uniformly applies heat for shrink film.
Control Panel: PLC or touchscreen for monitoring and adjustments.
Cooling Section: Ensures proper stabilization of film after heat application.
Installation Requirements
Level and stable floor surface
Adequate electrical supply
Compressed air supply if required
Proper ventilation
Integration space for conveyors
Maintenance Guide for Side Entry Wrapping Machine CCP-EC50
Daily Maintenance
Clean machine surfaces
Inspect film alignment
Check conveyor operation
Weekly Maintenance
Lubricate moving parts
Inspect electrical and pneumatic systems
Monthly Maintenance
Check heat tunnel and sealing mechanism
Replace worn parts
How to Choose the Right Side Entry Wrapping Machine CCP-EC50
Production Volume
Ensure the machine matches your required output.
Product Size Compatibility
Verify the machine supports your product dimensions.
Automation and Control Features
Look for advanced PLC control and touch screen operation.
Energy Efficiency
Consider power consumption and cost efficiency.
Reliability and Durability
Choose industrial-grade components for long-term use.
Common Issues and Solutions
| Issue | Cause | Solution |
|---|---|---|
| Film Wrinkle | Misaligned film or tension | Adjust film path and tension |
| Loose Wrap | Insufficient heat or sealing | Adjust temperature settings |
| Product Jamming | Conveyor misalignment | Align guides and check sensors |
| Uneven Shrink | Inconsistent heat distribution | Inspect heating elements |
Safety Considerations
Train all operators before use
Avoid direct contact with heat sources
Use protective gloves and eyewear
Inspect moving parts regularly
Follow local electrical and mechanical safety regulations
Future Trends in Side Entry Wrapping Technology
Smart automation and IoT integration
Energy-efficient heat shrinking
Compact modular designs for flexible production lines
Robotic-assisted wrapping
Data-driven monitoring and predictive maintenance
The Side Entry Wrapping Machine CCP-EC50 is a versatile and efficient solution for modern packaging lines. It enhances productivity, ensures consistent wrapping quality, reduces labor costs, and adapts to multiple industries. Its flexible design and high-speed operation make it a reliable choice for beverage, food, pharmaceutical, cosmetic, and industrial packaging applications.
