2.Workflow

The product is conveyed by the conveyor belt on the assembly line → conveyed by the conveyor belt → clamped by the product → electric eye detection → the label feeder mechanism receives the electric eye signal and sends the label → the label is quickly sent to the part that needs to be marked on the product → the label is pressed → the finished product is output through the plate chain conveyor belt

3.Mechanical structure and functional characteristics

Multi functional labeling machine: suitable for labeling square or round bottle products, with simple adjustment and wide applicability. It only requires a small amount of adjustment to complete the mutual conversion of various specifications of objects.

The product clamping belt mechanism achieves higher precision labelin
g.The layout of the label feeder is simple and reasonable, with high speed and stability. It adopts a double pressure roller structure to ensure the label is tightened and avoid label breakage caused by damage to the base paper die-cutting. The segmented clutch makes the tension more balanced.

1) Double pressure roller labeling is beneficial for improving the accuracy of labeling. As the label is rolled by the active pressure roller before labeling, it is beneficial to eliminate label wrinkles, improve labeling quality, and achieve the use of the last label.

2) The two-stage swing rod spring type label delivery clutch, with an additional belt type brake, achieves high-speed constant tension label delivery.

Using sensors from Germany and Japan for detection, high sensitivity and easy adjustment ensure the accuracy of labeling.

Servo motor drive, achieving true closed-loop control, high-precision subdivision, built-in absolute value encoder, meeting the requirements of high-speed and high-precision positioning.

The eight dimensional space adjustment of the header has a powerful and flexible adjustment ability, and the accurate labeling of any product can be adjusted within a few minutes.

Advanced and friendly independent human-machine interface control, with operational parameters that can be stored and called. Any abnormal situations are displayed on the human-machine interface and guided for troubleshooting. The operation is simple, and anyone can easily operate and quickly use this device.

Using imported electrical components from world-renowned brands, the control system adopts Mitsubishi PLC, and the labeling station adopts Panasonic servo motors from Japan to ensure the long-lasting stability and reliability of the entire machine.

All accessories, including chassis and conveyor lines, are made of stainless steel and aluminum alloy materials, which will never rust or pollute, ensuring compliance with GMP environmental requirements.

PU rubber roller, vulcanized and wear-resistant. Ultra high polymer stopper, wear-resistant, beautiful, and smooth. The spiral bevel gear adopts the Japanese Panasonic brand, which is wear-resistant and has a long service life.

All components are processed using CNC machining, with high-precision coordination to ensure the accuracy level of the equipment, smooth operation, and low noise.

A strong engineering design team can make personalized non-standard designs for special production requirements of customers at any time.

A printer can be installed to achieve online printing of production date, shelf life, etc.

Visual inspection and removal mechanisms can be installed to achieve the detection and removal of non-conforming products.
